Zeugma Panorama
Zeugma Panorama is a multiplace hyperbaric chamber designed for simultaneous treatment of two users, combining panoramic visibility, automated operation, and hi-end performance for professional HBOT environments.
- Multiplace chamber with two independent seats
- Operating pressure up to 2.4 ATA
- Panoramic acrylic windows for an open, claustrophobic-free experience
- Automated control system with preset clinical protocols
Zeugma Panorama Multiplace Hyperbaric Chamber is designed to deliver efficient and comfortable hyperbaric oxygen therapy for two users at the same time. Its multiplace configuration makes it an ideal solution for clinics, rehabilitation centers, and performance facilities seeking higher throughput without compromising comfort, safety, or treatment quality.
The chamber features an enclosed hard-shell structure with multiple panoramic acrylic windows that create a bright, open environment. This visual openness significantly reduces the feeling of confinement and enhances psychological comfort during longer HBOT sessions, which is especially important in professional and repeated-use settings.
Zeugma Panorama integrates advanced automation software that allows operators to easily configure, start, and monitor sessions through a digital control interface. Pressure levels, oxygen delivery, air breaks, and session durations can be customized according to individual protocols, while built-in preset programs support consistent and repeatable treatments. The system balances technical precision with user-centric design, offering a refined interior, intuitive operation, and reliable performance for daily professional use.
| Feature/Specification | Zeugma Panorama |
| Chamber Material | Ballistic steel |
| Chamber Dimension (LxWxH) | 199x135x186 cm |
| Max Pressure | 2.0 | 2.4 ATA |
| Chamber Weight | 750 kg |
| Modular Sections | 3 modules. Up to 77cm each |
| Oxygen Delivery (Dual) | BIBS & Free Flow Mask or Cannula |
| Control Tablet (Dual) | External 21″/Internal 16″ Tesla Style Touch Screen |
| Module Functions | Customizable protocols, 2-Way communication |
| Occupancy x Seating (Option*) | 2 x Luxury Lounge|Maybach Recliners* |
| Lighting | Adjustable LED RGB lights |
| Certifications Included | 2006/42/EC/ , 93/42/EEC (PED) |
| Certifications Optional | ASME PVHO-1, UKCA, MEDICAL CE |
| 3.0 ATA Medical CE | Extra |
| Customization Options | Paint RAL, Interior Lining, Maybach Recliners/Color, Panoramic Window |
| Compressor | |
| Dimensions (LxWxH) cm | 100x50x80cm |
| Weight (Kg) | 67 |
| Horse Power (HP) | 4 |
| Lpm Output | 564 |
| Noise Level (db) | 48 |
| Price | Included |
| Oxygen Concentrator (2 pieces required) | |
| Dimensions (LxWxH) | kg | 70x48x107cm | 155kg |
| Lpm | o2% | Pressure | 20Lpm | ±93% | 5 Bar |
| Watts | Horse Power (HP) | 2500W | 3.3hp |
| Noise Level (db) | ≤72 db |
| Units Required | 2 |
| Price/Unit | Extra |
| Chiller | |
| SMC Chiller (Japan) | 1kW@-10C|-10C-40C|50x38x64cm|40kg |
| Cooling Method | Air-cooled refrigeration |
| Price | Extra |
Panoramic Visibility
Multiple large acrylic windows provide full external visibility, creating an open and calming atmosphere that helps reduce anxiety and improve overall user experience during hyperbaric sessions.
Integrated BIBS System
The Built-In Breathing System delivers oxygen in sync with inhalation while safely removing exhaled CO₂. This design maintains ambient oxygen levels inside the chamber and supports high safety standards during operation.
Chiller System
A chiller system for hyperbaric oxygen therapy (HBOT) is a component that helps regulate and maintain the temperature inside the chamber. When users are inside the chamber, the increased atmospheric pressure can cause the temperature to rise. The chiller system counteracts this effect by efficiently cooling the chamber and maintaining an optimal temperature for a comfortable hyperbaric experience.
Automated Session Control
The digital touchscreen interface allows precise control over pressure, oxygen delivery, air breaks, and session duration. Automated operation reduces manual intervention and ensures consistent treatment protocols.
Preset Protocols
Seven built-in HBOT protocols support a range of applications, including cognitive performance, recovery, wound care, and wellness-focused treatments, while allowing customization for individual users.
User-Centric Interior Design
The chamber interior is designed around personal comfort and usability, offering ergonomic seating, high-quality materials, and clear communication systems for a relaxed and controlled treatment environment.
Safety and Manual Backup Systems
In addition to automation, the system includes manual safety components such as pressure relief valves, manometer, emergency stop button, and manual decompression control for added operational confidence.
Customization Options
- Exterior color customization (RAL options)
- Interior leather color selection
- Branding elements such as logos and custom details
- Additional entertainment or connectivity options
- Configuration of therapy and monitoring settings
Optional Certifications
- Compliance with applicable pressure vessel and safety standards
- CE-related conformity assessments depending on configuration and market
- Market-specific regulatory adaptations upon request
